Front Flip Type

Features
Pitch: 0.30-1.00mm
Circuits: >=4 pins
Contact Position: B/C
Mounting Type: SMT
Operation Direction: R/A
Product Height: 0.98-2.50mm
Cable Thickness: 0.2 & 0.3mm

Advance Search

Series


Family

Pitch (mm)

PCB Mounting

Operation Direction

Product Height (mm)

CableType

Contact Position

Cable Thickness(mm)

Circuits

High Speed Support

50505-xxxxx-xxx

50505-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

1.60

Normal

B/C

0.3±0.03

4,6,7,8,9,10,12,13,14,16,18,20

-

50506-xxxxx-xxx

50506-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.60

Normal

B/C

0.3±0.03

4,5,6,8,9,10,11,12,14,15,16,18,19,20,21,22,23,24,26,27,28,30,32,33,34,36,40

-

50507-xxxxx-xxx

50507-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.60

Normal

B/C

0.3±0.03

6,8,10,12,13,14,18,20,24,26,28,30,33,40

-

50515-xxxxx-xxx

50515-xxxxx-xxx

Front Flip Easy-on

0.30

SMT

R/A

1.20

Normal

B/C

0.2±0.03

11,13,15,17,21,23,25,27,31,33,35,39,41,45,51,61

-

50517-xxxxx-xxx

50517-xxxxx-xxx

Front Flip Easy-on

0.40

SMT

R/A

1.20

With Notch

B/C

0.2±0.03

6,10,18,21,25,30,40,57,60

-

50519-xxxxx-xxx

50519-xxxxx-xxx

Front Flip Easy-on

0.80

SMT

R/A

2.00

Normal

B/C

0.3±0.03

4,6,8,12,26,34

-

50520-xxxxx-xxx

50520-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

2.50

With Ear

B/C

0.3±0.03

5,6,8,10,12,13,15,16,18,20,40,45,50,60,64,68,80

-

50521-xxxxx-xxx

50521-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

0.98

Normal

B/C

0.3±0.03

4,5,6,8,7,9,10,11,12,13,14,16,18,20,21,22,24,25,30,40,43

-

50523-xxxxx-xxx

50523-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

2.00

With Ear

B/C

0.3±0.03

15,20,25,30

-

50524-xxxxx-xxx

50524-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

2.00

With Ear

B/C

0.3±0.03

4,6,10,25,30,34

-

50671-xxxxx-xxx

50671-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

2.00

With Ear

B/C

0.3±0.03

10,15,22,24,26,28,30,32,40,45,50,55

-

50672-xxxxx-xxx

50672-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

2.00

With Ear

B/C

0.3±0.03

32,39

-

50675-xxxxx-xxx

50675-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.60

Normal

B/C

0.3±0.03

6,10,16,40

-

50690-xxxxx-xxx

50690-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

2.00

With Ear

B/C

0.3±0.03

26,28,32

-

50692-xxxxx-001

50692-xxxxx-001

Front Flip Easy-on

1.00

SMT

R/A

2.00

With Ear

B/C

0.3±0.03

30

-

50693-xxxxx-xxx

50693-xxxxx-xxx

Front Flip Easy-on

0.30

SMT

R/A

1.20

Normal

B/C

0.2±0.02

39

-

50699-xxxxx-xxx

50699-xxxxx-xxx

Front Flip Easy-on

0.80

SMT

R/A

1.20

With Notch

B/C

0.2±0.03

24,26,30,32

-

51503-xxxxx-001

51503-xxxxx-001

Front Flip Easy-on

1.00

SMT

R/A

1.80

With Ear

B/C

0.3±0.03

18,26,30,32,34

-

51510-xxxxx-xxx

51510-xxxxx-xxx

Front Flip Easy-on

0.80

SMT

R/A

2.00

With Ear

B/C

0.3±0.03

30,32,34

-

51517-xxxxx-xxx

51517-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.75

With Ear

B/C

0.3±0.03

40

-

51518-xxxxx-xxx

51518-xxxxx-xxx

Front Flip Easy-on

0.80

SMT

R/A

1.75

With Ear

B/C

0.3±0.03

24,26,30

-

51519-xxxxx-xxx

51519-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

2.00

With Ear

B/C

0.3±0.03

16,24,20,28,30,32,40,55

-

51522-xxxxx-xxx

51522-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

2.00

Normal

B/C

0.3±0.03

4,6,8,10,12,14,16,20,26,30,32,40,60

-

51524-xxxxx-xxx

51524-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

2.00

Normal

B/C

0.3±0.03

4,6,8,10,12,14,16,22,24,26,30

-

51530-xxxxx-002

51530-xxxxx-002

Front Flip Easy-on

0.50

SMT

R/A

1.80

With Ear

B/C

0.3±0.03

4,6,8,10,12,14,15,20,24,25,26,30

-

51536-xxxxx-xxx

51536-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.20

Normal

B/C

0.3±0.03

4,5,6,8,9,10,12,14,15,16,17,20,21,22,24,26,30,40

-

51537-xxxxx-xxx

51537-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.60

normal

B/C

0.3±0.03

30

-

51540-xxxxx-xxx

51540-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.80

With Ear

B/C

0.3±0.03

8,10,12,14,16,18,20,22,24,30,32,34,36.40,42,44,45,46,50,56,60

USB3.0 (5Gbps); SATA Gen 3(6Gbps)

51547-xxxxx-001

51547-xxxxx-001

Front Flip Easy-on

0.50

SMT

R/A

2.00

normal

B/C

0.3±0.03

6,10,14,26,32

-

51548-xxxxx-xxx

51548-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

2.00

normal

B/C

0.3±0.03

12,15,40

-

51549-xxxxx-xxx

51549-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

2.00

normal

B/C

0.3±0.03

4,6,10,16,24,26

-

51551-xxxxx-xxx

51551-xxxxx-xxx

Front Flip Easy-on

0.80

SMT

R/A

1.80

With Ear

B/C

0.3±0.03

34,36,40

-

51555-xxxxx-xxx

51555-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.80

With Ear

B/C

0.3±0.03

50

-

51556-xxxxx-xxx

51556-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.20

Normal

B/C

0.3±0.03

40

-

51558-xxxxx-xxx

51558-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

1.30

normal

B/C

0.3±0.03

4,6,8,10,12

-

51561-xxxxx-xxx

51561-xxxxx-xxx

Front Flip Easy-on

0.80

SMT

R/A

1.50

With Ear

B/C

0.3±0.03

32

-

51569-xxxxx-xxx

51569-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.45

With Notch

B/C

0.3±0.03

32,36

-

51570-xxxxx-xxx

51570-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

1.45

With Notch

B/C

0.3±0.03

4,8,12

-

51571-xxxxx-xxx

51571-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

1.20

Normal

B/C

0.3±0.03

4,6,8,12

-

51574-xxxxx-xxx

51574-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

1.30

With Notch

B/C

0.3±0.03

8,10

-

51575-xxxxx-xxx

51575-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

1.80

With Ear

B/C

0.3±0.03

4

-

51578-xxxxx-xxx

51578-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.60

normal

B/C

0.3±0.03

4,5,6,8,10,11,12,14,15,16,18,19,20,21,22,23,24,26,27,28,30,32,33,34,36,40

-

51579-xxxxx-xxx

51579-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.60

With Notch

B/C

0.3±0.03

4,8,12,16,18,23

-

51580-xxxxx-xxx

51580-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.30

With Notch

B/C

0.3±0.03

6,8,11,12,32

-

51581-xxxxx-xxx

51581-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

2.00

With Notch

B/C

0.3±0.03

4,6

-

51586-xxxxx-xxx

51586-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

1.60

With Ear

B/C

0.3±0.03

28,32

-

51590-xxxxx-xxx

51590-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

1.20

Normal

B/C

0.3±0.03

4,6,8

-

51593-xxxxx-xxx

51593-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

2.00

With Ear

B/C

0.3±0.03

28,32

-

51595-xxxxx-xxx

51595-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

2.00

Normal

B/C

0.3±0.03

12, 40

-

51607-xxxxx-xxx

51607-xxxxx-xxx

Front Flip Easy-on

0.30

SMT

R/A

1.06

Normal

B/C

0.2±0.03

17,19,39,41,45,51,61,67,71

-

51614-xxxxx-002

51614-xxxxx-002

Front Flip Easy-on

0.50

SMT

R/A

1.00

Normal

B/C

0.3±0.03

4,5,6,7,8,9,10,12,13,14,15,18,20,22,24,25,30,40

-

51615-xxxxx-xxx

51615-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

2.00

Normal

B/C

0.3±0.03

6

-

51617-xxxxx-xxx

51617-xxxxx-xxx

Front Flip Easy-on

0.80

SMT

R/A

1.75

With Ear

B/C

0.3±0.03

26,32

-

51625-xxxxx-xxx

51625-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.80

With Ear

B/C

0.3±0.03

6,10,12,14,16,18

-

51628-xxxxx-xxx

51628-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

1.80

Normal

B/C

0.3±0.03

26,30

-

51629-xxxxx-xxx

51629-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

1.80

With Ear

B/C

0.3±0.03

4

-

51636-xxxxx-xxx

51636-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

2.20

With Notch

B/C

0.32±0.03

96

-

51637-xxxxx-xxx

51637-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

1.00

Normal

B/C

0.3±0.03

4,6,8

-

51639-xxxxx-xxx

51639-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.80

With Ear

B/C

0.3±0.03

30,40,44,48,50

-

51643-xxxxx-xxx

51643-xxxxx-xxx

Front Flip Easy-on

0.80

SMT

R/A

2.00

With Ear

B/C

0.3±0.03

30

-

51645-xxxxx-xxx

51645-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

0.98

Normal

B/C

0.2±0.03

4

-

51646-xxxxx-xxx

51646-xxxxx-xxx

Front Flip Easy-on

0.80

SMT

R/A

2.00

With Ear

T/C

0.3±0.03

30

-

51647-xxxxx-xxx

51647-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

2.00

With Ear

B/C

0.3±0.03

10

-

51651-xxxxx-xxx

51651-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.10

With Ear

B/C

0.3±0.03

10

-

51652-xxxxx-xxx

51652-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

2.00

normal

B/C

0.3±0.03

4,5,6,8,10,12,14,16,18,20,22,24,26,28,30,32,34,36,40,45,50,56,60

-

51653-xxxxx-xxx

51653-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

2.00

normal

B/C

0.3±0.03

4,5,6,7,8,10,12,14,16,18,20,22,23,24,26,28,30

-

51654-xxxxx-xxx

51654-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

2.00

normal

B/C

0.3±0.03

4,6,7,8,10,12,14,16,18,20,22,24,26,28,30

-

51656-xxxxx-xxx

51656-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.80

With Ear

B/C

0.3±0.03

12

-

51661-xxxxx-xxx

51661-xxxxx-xxx

Front Flip Easy-on

0.80

SMT

R/A

1.80

With Ear

B/C

0.3±0.03

36

-

51677-xxxxx-002

51677-xxxxx-002

Front Flip Easy-on

1.00

SMT

R/A

2.00

With Ear

B/C

0.3±0.03

15,20,30

-

51678-xxxxx-xxx

51678-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

1.90

With Ear

B/C

0.3±0.03

4,6,8

-

51686-xxxxx-xxx

51686-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

1.55

With Notch

B/C

0.3±0.03

8,10

-

51689-xxxxx-xxx

51689-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.60

With Notch

B/C

0.3±0.03

12

-

51693-xxxxx-xxx

51693-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

2.00

With Ear

B/C

0.3±0.03

40

-

51694-xxxxx-xxx

51694-xxxxx-xxx

Front Flip Easy-on

0.80

SMT

R/A

1.75

With Ear

B/C

0.3±0.03

30

-

51695-xxxxx-xxx

51695-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.23

With Ear

B/C

0.3±0.03

14,30,40,45,50

USB Type C Gen 2(10Gbps)

51698-xxxxx-xxx

51698-xxxxx-xxx

Front Flip Easy-on

0.80

SMT

R/A

1.20

With Notch

B/C

0.2±0.03

30

-

51699-xxxxx-xxx

51699-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.30

With Notch

B/C

0.3±0.03

6

-

52503-xxxxx-xxx

52503-xxxxx-xxx

Front Flip Easy-on

0.30

SMT

R/A

1.06

With Ear

B/C

0.2±0.03

23,29,33,49,51

-

52504-xxxxx-xxx

52504-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.20

With Ear

B/C

0.3±0.03

40

-

52505-xxxxx-xxx

52505-xxxxx-xxx

Front Flip Easy-on

0.80

SMT

R/A

1.80

With Ear

B/C

0.3±0.03

26

-

52507-xxxxx-xxx

52507-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

1.00

Normal

B/C

0.3±0.03

8

-

52509-xxxxx-xxx

52509-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.10

With Ear

B/C

0.3±0.03

4,6,8,10

-

52515-xxxxx-xxx

52515-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.00

Normal

B/C

0.3±0.03

8

-

52516-xxxxx-xxx

52516-xxxxx-xxx

Front Flip Easy-on

0.80

SMT

R/A

1.80

With Ear

B/C

0.3±0.03

30

-

52526-xxxxx-xxx

52526-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.23

With Ear

B/C

0.3±0.03

30,40

-

52527-xxxxx-xxx

52527-xxxxx-xxx

Front Flip Easy-on

0.30

SMT

R/A

0.95

With Ear

B/C

0.2±0.03

11,45

-

52531-xxxxx-xxx

52531-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.46

Normal

B/C

0.3±0.03

24

-

52532-xxxxx-xxx

52532-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

0.96

With Notch

B/C

0.3±0.03

4,5,6,8,10,26,30,34,40

-

52533-xxxxx-xxx

52533-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

2.00

With Ear

B/C

0.3±0.02

34

-

52539-xxxxx-xxx


Front Flip Easy-on

1.00

SMT

R/A

2.00

Normal

B/C

0.3±0.03

22

-

52545-xxxxx-xxx

52545-xxxxx-xxx

Front Flip Easy-on

0.50

SMT

R/A

1.28

With Notch

B/C

0.3±0.03

12

-

52546-xxxxx-xxx

52546-xxxxx-xxx

Front Flip Easy-on

1.00

SMT

R/A

1.28

With Notch

B/C

0.3±0.03

14

-

52565-xxxxx-xxx

52565-xxxxx-xxx

Front Flip Easy-on

0.50

SMT; Solder Tape : L TYPE

R/A

1.80

With Ear

B/C

0.3±0.03

32,34,40

USB3.0 (5Gbps); SATA Gen 3(6Gbps)

Abbreviation
