Electrical
Voltage: 30 V AC
Current: 1.8 A
Contact Resistance: 50 mΩ MAX.
Dielectric Withstanding Voltage: 100 V AC/rms
Insulation Resistance: 100 MΩ MIN.
Operating Temperature: -55℃ ~ +85℃
Specification(Abbreviation)
Family: A type
Interface: Reverse Sink
PCB Mounting: SMT
Operation Direction: R/A
Center Height (mm): -2.04
Product Length (mm): 15.15
Product Height (mm): 7.46
PCB to Top Height (mm): 2.56
Download > 3D
Download
2D
SPEC
3D
