51998-008xx-xxx

Electrical

Voltage: 36V AC
Current: 5.0A
Contact Resistance:
30 m Ω Max.(initial);
20 m Ω Max. (Final)
Dielectric Withstanding Voltage: 500V AC/rms
Insulation Resistance: 500 MΩ min.
OperatingTemp : -40℃~ +85℃

Reference Information
Mated P/N: 51973



Specification(Abbreviation)

Family: Blade Male

Pitch(mm): 2.50

PCB Mounting: T/H

Operation Direction: R/A

Above PCB Height (mm): 6.10

Mates With: 51973

Current(A): 6.0

Screw (Yes/No): No

Circuits: 8
